Electric Motor Manual Starter
With Adjustable Current Range And Service Lock Out.
Hold Mouse Over Photo To Enlarge.
Type 230V 400V 690V 230V 460V 575V Icu [kA] Ics [kA] 10 6-10 130 3 4 7.5. 3 7.5 10 100 143 13 9-13 169 3 5.5 11 3 7.5 10 100 100 17 11-17 221 4 7.5 11 5 10 15 50 50 MMS-63H L 22 14-22 286 4 7.5 15 7.5 15 20 50 50 {High break] 26 18-26 338 5.5 11 18.5 10 20 25 50 50 32 22-32 416 7.5 15 22 10 25 30 50 50 40 28-40 520 7.5 18.5 30 15 30 40 50 50 50 34-50 650 11 22 45 15 40 50 50 50 63 45-63 819 15 30 55 20 50 60 50 50 17 11-17 221 4 7.5 11 5 10 15 100 100 22 14-22 286 4 7.5 15 7.5 15 20 100 50 26 13-26 338 5.5 11 18.5 10 20 25 100 50 MMS-100H L 32 22-32 416 7.5 15 22 10 25 30 100 50 {High break] 40 2S-40 520 7.5 18.5 30 15 30 40 100 50 50 34-50 650 11 22 45 15 40 50 100 50 63 45-63 819 15 30 55. 20 50 60 100 . 50 75 55-75 975 22 37 63 25 60 75 75 50 90 70-90 1170 30 45 75 30 75 100 75 50 100 80-100 1300 30 45 90 40 75 100 75 50 Rated Operational Current I (A) Thermal Release Adjustme nt Range Magnetic release Operating curren t [A] Switching of 3 phase AC motors, A3-2, AC-3 {50/60HZ) [HP] [60HZ] 400/415V 3-phase [kW] 3-phase
